K33321924-0
Dual Bearing Combination Steering Mechanism
6061 aluminum wheel core, high-quality CPU tread, wear-resistant, heat-resistant, hydrolysis-resistant, small swivel radius, low steering resistance.
Capable of operating at speeds ≤ 5.4 KM/H under rated load.
| Wheel Material | Aluminum Core Polyurethane (Yellow) |
|---|---|
| Wheel Surface Hardness | 95±3° shore A |
| Surface Treatment | Electrogalvanized |
| Extended Function | Anti-Static: Resistance ≤ 1010Ω |
| Parameters Model (mm) | Wheel diameter | Tread width | Mounting Height | Eccentricity | Swivel rotation radius | Loadability |
|---|---|---|---|---|---|---|
| 3" | 75 | 38*2 | 124 | 28 | 70 | 400kg |
| 4" | 100 | 38*2 | 136 | 28 | 84 | 500kg |
