K3486144-0
| Size | Diameter (mm) | Wheel Width (mm) | Mounting Height (mm) | Bushing Size (mm) | Screw Rod Diameter (mm) | Load Capacity (kg) |
|---|---|---|---|---|---|---|
| 1.5 inch | 40 | 22 | 60 | 22×50 | M12×60 | 35 |
| 2 inch | 60 | 27 | 70 | 22×50 | M12×60 | 50 |
| 3 inch | 75 | 32 | 105 | 22×50 | M12×60 | 80 |
| 4 inch | 100 | 32 | 129 | 22×50 | M12×60 | 90 |
| 5 inch | 125 | 32 | 153 | 22×50 | M12×60 | 100 |
