K93801910-0
Japanese Style Heavy-Duty Lifting Jacks | |||||
| Model | Base Plate Size (mm) | Max Lift (mm) | Min. Height (mm) | Hole Dia. (mm) | Base Hole Spacing (mm) |
|---|---|---|---|---|---|
| 4" | 120*120 | 151 | 125 | 11 | 85x100/85x100 |
| 5" | 120*120 | 172 | 146 | 11 | 85x100/85x100 |
| 6" | 120*120 | 198 | 158 | 11 | 85x100/85x100 |
| 8" | 120*120 | 248 | 208 | 11 | 85x100/85x100 |
American Style Medium-Duty Lifting Jacks | |||||
| Model | Base Plate Size (mm) | Max Lift (mm) | Min. Height (mm) | Hole Dia. (mm) | Base Hole Spacing (mm) |
| 2-3" | 92*64 | 121 | 94 | 8.2 | 71x78/45 |
| 2-4" | 92*64 | 140 | 114 | 8.2 | 71x78/45 |
| 2-4" | 92*64 | 159 | 131 | 8.2 | 71x78/45 |
American Style Heavy-Duty Lifting Jacks | |||||
| Model | Base Plate Size (mm) | Max Lift (mm) | Min. Height (mm) | Hole Dia. (mm) | Base Hole Spacing (mm) |
| 4x2 | 100*114 | 149 | 125 | 11 | 67x76/76x92 |
| 5x2 | 100*114 | 169 | 141 | 11 | 67x76/76x92 |
| 6x2 | 100*114 | 197 | 169 | 11 | 67x76/76x92 |
| 6x2 | 100*114 | 247 | 219 | 11 | 67x76/76x92 |
