K58670537-0
| Model | Total Load Capacity (4 wheels) | Single Wheel Load Capacity | Exposed Thread Length | Thread Diameter | Base Plate Size | Mounting Hole Spacing | Single Wheel Diameter | Adjustable Height Lifted Height | Wheel Thickness |
|---|---|---|---|---|---|---|---|---|---|
| GD40F | 100kg | 50kg | 10mm | M8 | 55mm | 42/6.5mm | 42mm | 71+10mm | 20mm |
| GD60F | 500kg | 250kg | 15mm | M12 | 73mm | 58/7mm | 50mm | 82+10mm | 25mm |
| GD80F | 1000kg | 500kg | 15mm | M12 | 90mm | 70/9mm | 63mm | 102+15mm | 28mm |
| GD100F | 1500kg | 750kg | 20mm | M16 | 95mm | 70/11mm | 75mm | 120+12mm | 30mm |
| GD120F | 2000kg | 1000kg | 20mm | M16 | 95mm | 70/11mm | 75mm | 120+12mm | 30mm |
