H6843487-0
| Size | Wheel Diameter (mm) | Wheel Width (mm) | Screw Rod Size (mm) | Base Plate Size (mm) | Hole Spacing (mm) | Hole Diameter (mm) | Mounting Height (mm) | Load Capacity (kg) |
|---|---|---|---|---|---|---|---|---|
| 1.5 inch | 40 | 21 | M12*25 | 66*48 | 49*32 | 6 | 60 | 70 |
| 2 inch | 50 | 30 | M12*25 | 72*54 | 55*38 | 7 | 71 | 80 |
| 2.5 inch | 63 | 40 | M12*25 | 95*68 | 72*43 | 8.5 | 93 | 180 |
| 3 inch | 75 | 45 | M12*25 | 105*80 | 80*60 | 8.5 | 105 | 220 |
