G56672922-0
| Specification | Net Weight (Single) Fixed | Net Weight (Single) Swivel | Net Weight (Single) Brake | Packing Quantity | Wheel Material | Wheel Diameter | Wheel Width | Installation Height | Turning Radius | Bearing | Base Plate Size | Hole Spacing | Hole Diameter | Base Plate & Bracket Thickness | Load Capacity |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3 inch | 0.331 | 0.364 | 0.425 | 60 | RB | 75 | 25 | 92 | 65 | Needle Roller Bearing | 81x68 | 60x45 | 10.3x4 | 1.8/1.8 | 50 |
| 3.5 inch | 0.3575 | 0.3951 | 0.4415 | 40 | RB | 85 | 27 | 110 | 84 | Needle Roller Bearing | 101x84 | 80x60 | 10.3x4.5 | 2.0/2.0 | 60 |
| 4 inch | 0.559 | 0.677 | 0.793 | 38 | RB | 100 | 30 | 129 | 97 | Needle Roller Bearing | 101x84 | 80x60 | 10.3x4.5 | 2.0/2.0 | 70 |
| 5 inch | 0.837 | 0.9 | 1.027 | 28 | RB | 125 | 37.5 | 153 | 102 | Needle Roller Bearing | 101x84 | 80x60 | 10.3x4.5 | 2.0/2.0 | 100 |
| 6 inch | 1.67 | 1.78 | 2.125 | 12 | RB | 160 | 40 | 188 | 107 | Needle Roller Bearing | 135x105 | 105x75 | 10.3x4.5 | 2.0/2.0 | 145 |
| 8 inch | 2.125 | 2.375 | 2.7 | 8 | RB | 200 | 50 | 220 | 115 | Needle Roller Bearing | 135x105 | 105x75 | 10.3x4.5 | 2.5/2.5 | 185 |
